Debug tools
Last modified by Lev Andronov on 2024/11/03 16:49
Vision Point installation comes with a bunch of debug tools. This tools is useable mostly for internal debugging process, but you can use it in some cases if you know what you doing.
The hierarchy and a brief description:
Vision Point I
| debug_tools | ||
| KYInfo.bat | Batch script that collects all Vision Point logs and system info | |
| KYRestart.bat | Batch script to restart KAYA Service | |
| Dbgview.exe | A legacy tool that captures debug output from programs and device drivers | |
| DebugView++.exe | An open-source tool that serves as an enhanced version of DebugView | |
| DebugView++.dbconf | Configuration file for DebugView++ | |
| depends.exe | Executable dependencies | |
| └── Software_Settings | ||
| ├── IsImplemented.reg | Enable certain features | |
| ├── non-butterfly-camera_detection_debug.reg | Camera detection for firmware before 5.0 | |
| ├── QtNativeDialog-OFF.reg | Disables Qt Native Dialog | |
| ├── QtNativeDialog-ON.reg | Enables Qt Native Dialog | |
| ├── UrlChunkSize_1.reg | Sets URL chunk size to 1 | |
| ├── UrlChunkSize_default.reg | Resets URL chunk size to default | |
| ├── VisionPoint_Logger2Dbgview.reg | Switches logging to Dbgview.exe | |
| ├── VisionPoint_Logger2File.reg | Switches logging to the default file | |
| ├── VisionPoint_Logger2NULL.reg | Switches logging level to zero | |
| └── FG firmware 5+ | ||
| ├── AckThrottle-Sleep.reg | Acknowledgment throttle sleep setting | |
| ├── CommandControllerCXPGrabber_v1.reg | Switches to CXP controller v1 | |
| ├── CommandControllerCXPGrabber_v2.reg | Switches to CXP controller v2 | |
| ├── CommandControllerCXPGrabberOuterLockOff.reg | Switches to 'OuterLock=Off' for CXP controller v1 | |
| ├── CommandControllerCXPGrabberOuterLockOn.reg | Switches to 'OuterLock=On' for CXP controller v1 | |
| ├── VisionPoint_Logger_Butterfly_Dumps_DebugGrabberCmds.reg | Butterfly log dumps | |
| ├── VisionPoint_Logger_CommandControllerCXPGrabber-Debug.reg | Enables debug for Command Controller CXP Grabber |
